Garmin ECHOMAP Ultra 2 Sonar Chartplotter, 122SV, 12", WW, with GT56 Transducer

Garmin ECHOMAP Ultra 2, 122SV, 12", WW, with GT56 Transducer

The Garmin ECHOMAP Ultra 2 122sv is a state-of-the-art marine chartplotter featuring a 12.1-inch IPS touchscreen, ideal for advanced fishing and navigation. Compatible with LiveScope sonar and multi-band GPS, this model delivers superior performance, extensive connectivity, and an intuitive interface. It is designed for vessels requiring precision, excellent visibility, and full integration with the Garmin ecosystem.

Physical Features and Performance:

• Physical dimensions: 34.1x22.9x9.8cm (13.4″x9″x3.9″);
• Weight: 2.5kg (5.5lbs);
• Water resistance: IPX7;
• Touchscreen: yes;
• Display type: WXGA, IPS;
• Display size: 26.1x16.3cm; 30.7cm diagonal (12.1″);
• Display resolution: 1280x800 pixels;
• Mounting options: bail or flush mount;
• Assistance buttons: touchscreen with dedicated keys.

Charts and Memory:

• Supports data cards: 2x microSD;
• Waypoints: 5000;
• Track points: 50000;
• Tracks: 50 saved tracks;
• Routes: 100.

Sensors:

• GPS;
• GLONASS;
• Galileo;
• BeiDou;
• Built-in receiver: yes;
• Receiver: 10Hz;
• NMEA 2000 compatible;
• Supports WAAS;
• Supports multi-band and multi-constellation GPS.

Optional Chart Support:

• BlueChart g3;
• BlueChart g3 Vision;
• Garmin Navionics+;
• Garmin Navionics Vision+;
• TOPO 100K;
• Standard charts;
• Garmin Quickdraw Contours.

Chartplotter Features:

• AIS;
• DSC;
• Supports Fusion-Link radios;
• ActiveCaptain compatible: yes;
• Included navigation features.

Electrical Network:

• Power supply voltage: 9–18V DC;
• Typical current at 12V DC: 2.5A;
• Maximum current at 12V DC: 5A;
• Maximum power consumption at 10V DC: 36W.

Sonar Features and Specifications:

• Sonar display: yes;
• Power output: 600W;
• Traditional sonar: built-in single channel CHIRP (70/83/200kHz, L/M/H CHIRP);
• ClearVu: built-in 260/455/800/1000/1200kHz;
• SideVu: built-in 260/455/800/1000/1200kHz;
• Panoptix sonar: compatible;
• LiveScope: compatible.

Connections:

• NMEA 2000 ports: 1;
• Garmin Marine Network ports: 2 (large connector);
• Transducer ports: 12-pin scanning sonar;
• ANT: yes;
• Garmin Wi-Fi (local connection): yes;

Package Contents:

• ECHOMAP Ultra 122sv;
• GT56UHD-TM Transducer;
• Power cable;
• Mounting bracket with quick-release base;
• Protective sun hood;
• Hardware;
• Documentation.
