Shimano Stella SW D Spinning Reel

Shimano Stella SW D Reel

The Shimano Stella SW reel is the flagship model in Shimano’s saltwater range, developed for anglers who demand maximum performance, high durability and reliability in the toughest conditions. Designed for marine use, this reel combines advanced technologies with a robust construction, making it suitable for landing large fish using techniques such as offshore spinning, vertical jigging or shore jigging.

At the heart of the mechanism is the HAGANE Gear, complemented by InfinityXross and InfinityDrive technologies, which optimize power transfer, reduce internal friction and maintain smooth retrieves even under heavy load. The result is precise and efficient operation during long fights with powerful species.

The drag system benefits from Heat Sink Drag and XX-Tough Drag technologies, which help dissipate heat efficiently and enhance braking performance during extreme loads. Oversized drag discs provide progressive and consistent braking, offering greater control over large fish.

For protection of the mechanism in the marine environment, the Stella SW is built to limit water and contaminant ingress, offering high corrosion resistance and durability suited to intensive use. The rugged construction and integrated technologies make this reel a tool for anglers seeking consistent performance in the most demanding outings.

Variants from size 14000 feature an elongated (oval) knob.

Features:

• Body material: Hagane forged steel;
• Long-cast spool in cold-forged aluminium;
• Cross Carbon Drag;
• Hagane gears;
• Water-resistant drag;
• Heat Sink Drag braking system;
• IPX8 water-resistant body;
• Rigid Support Drag;
• X-Protect technology;
• X-Rigid Bail;
• X-Rigid Gear;
• X-Rigid Handle;
• X-Rigid Rotor;
• X Touch Drag;
• InfinityDrive technology;
• Silent Drive system;
• Propulsion Line Management System;
• X-Protect technology (corrosion protection);
• One Piece Bail.
• Variants:
  • 4000 XG
    • Spool capacity: 0.30mm/180m;
    • Gear ratio: 6.2:1;
    • Line retrieval per handle turn: 101cm;
    • Weight (manufacturer specification): 360g;
    • Max. Drag Power: 11kg;
    • Bearings: 11;
  • 5000 HG
    • Spool capacity: 0.33mm/200m;
    • Gear ratio: 5.71;
    • Line retrieval per handle turn: 97cm;
    • Weight (manufacturer specification): 425g;
    • Max. Drag Power: 13kg;
    • Bearings: 12;
  • 5000 XG
    • Spool capacity: 0.33mm/200m;
    • Gear ratio: 6.2:1;
    • Line retrieval per handle turn: 105cm;
    • Weight (manufacturer specification): 425g;
    • Max. Drag Power: 13kg;
    • Bearings: 12;
  • 6000 PG
    • Spool capacity: 0.33mm/240m;
    • Gear ratio: 4.7:1;
    • Line retrieval per handle turn: 86cm;
    • Weight (manufacturer specification): 440g;
    • Max. Drag Power: 13kg;
    • Bearings: 12;
  • 6000 HG
    • Spool capacity: 0.33mm/240m;
    • Gear ratio: 5:7:1;
    • Line retrieval per handle turn: 104cm;
    • Weight (manufacturer specification): 440g;
    • Max. Drag Power: 13kg;
    • Bearings: 12;
  • 6000 XG
    • Spool capacity: 0.33mm/240m;
    • Gear ratio: 6.2:1;
    • Line retrieval per handle turn: nespecificat;
    • Weight (manufacturer specification): 425g;
    • Max. Drag Power: 13kg;
    • Bearings: 13.
  • 8000 PG
    • Spool capacity: nespecificat;
    • Gear ratio: 4.8:1;
    • Line retrieval per handle turn: 92cm;
    • Weight (manufacturer specification): 635g;
    • Max. Drag Power: 25kg;
    • Bearings: 12.

• • 8000 HG
    • Spool capacity: nespecificat;
    • Gear ratio: 5.6:1;
    • Line retrieval per handle turn: 107;
    • Weight (manufacturer specification): 630g;
    • Max. Drag Power: 25kg;
    • Bearings: 12.
  • 10000 PG

    • Spool capacity: 0.20mm/220m;
    • Gear ratio: 4.8:1;
    • Line retrieval per handle turn: 99cm;
    • Weight (manufacturer specification): 680g;
    • Max. Drag Power: 25kg;
    • Bearings: 12.
  • 10000 HG

    • Spool capacity: 0.20mm/220m;
    • Gear ratio: 5.6:1;
    • Line retrieval per handle turn: 116cm;
    • Weight (manufacturer specification): 680g;
    • Max. Drag Power: 25kg;
    • Bearings: 12.
  • 14000 XG

    • Spool capacity: 0.47mm/240m;
    • Gear ratio: 6.2:1;
    • Line retrieval per handle turn: 134cm;
    • Weight (manufacturer specification): 685g;
    • Max. Drag Power: 25kg;
    • Bearings: 12.
  • 18000 HG

    • Spool capacity: 0.52mm/310m, 0.57mm/240m, 0.62mm/200m;
    • Gear ratio: 5.7:1;
    • Line retrieval per handle turn: 128cm;
    • Weight (manufacturer specification): 900g;
    • Max. Drag Power: 30kg;
    • Bearings: 13+1.

Video presentation Shimano Stella SW D Spinning Reel
